20M HOWO telescopic boom aerial work platform truck

Description

★★★★★FunctionAnd Introduction:

20M HOWO telescopic boom aerial work platform truck (also called Man Lifter truck, truck mounted aerial work platform , knuckle boom aerial platform truck,Telescoping boom aerial platform, ISUZU Aerial working platfrom truck, aerial lift, hydraulic beam lifter, hydraulic aerial platform vehicle, aerial boom lift, bucket truck, overhead working truck, sky lift truck,etc).mainly used for the street lights maintenance, high-rise building maintenance, cleaning, maintenance, also used for elevator installation, ship repairing and cliff homework, etc, is essential to the construction machinery.

Similar Key Words: Telescopic boom aerial platform truck, telescopic boom lifts, telescopic aerial truck , telescopic working platform truck, articulated telescopic aerial truck, articulated basket platform truck,etc

★★★★★★★★★★aerial platform truck can be divided into many types:
1. According to boom type,there are telescopic boom aerial platform truck and folding boom aerial platform truck.
2. According to working height ,there are 12m ,14m,16m,18m,20m,22m, 24m,26m, 28m,30m,45m aerial work platform truck.
★★★★★Product Advantage:
1. Good chassis ensure best driving performance
2. Famous engine ,high quality ,stable performance,super powerful
3. Rational structure ,full computer control, operation the remote control ,lifting stable,more safe
4. 200-400kg platform load capacity, Optional carton steel, stainless steel and fiberglass material
5. 8-30M working height is avaliable
6. Professional customized service

★★★★★Product Parameter:

12M 14M 15M 16M 18M 20M SINOTRUK HOWO telescopic boom aerial work platform truck
Outline size(L×W×H) (mm)	6500X2200X3200		Brand				SINOTRUK HOWO
Rated load(kg)	/		Empty mass(Kg)：				6850
Full mass(kg)	7300		Emission standard				EURO 2
Engine Information
Power	116HP/3760CC		Manufacture			YUNNEI engine
Chassis Information
Wheelbase(mm)：	3360			Axle load(kg) F/R		2550/4750
Tire	7.00R16			Max speed (km/h)：		95
Front suspension(mm)	1130			Rear suspension(mm)		2085
Front track(mm)	1650			Rear track(mm)		1540
Approach angel(°)	19			Departure angle(°)		13
Steering	Power Steering			Brake		Air brake
Configuration	Straight head ,1 row ,electric window and door,air-condition
Special function
Max. working height(m)		12M 14M 15M 16M 18M 20M			Turning angle (°)			360°
Cage capacity(kg)		200 KG			Cage rotate angle			360°
Configuration		1. The control system is set in the upper and lower end of the truck, electric and manual double control system, with remote control. 2.Hydraulic lifting system: 360°rotation; Equipped with hydraulic legs ,Good stability, simultaneous or independent operation, suitable for a variety of conditions 3. The vehicle electric appliance adopts CAN control system , Self regulating balance , steady lifting, truck body more stable. 4. Equipped with Emergency power unit and cylinder locking function , more safe.
Trade terms
Quote Lifetime	30days (we promise the quote is effective in the lifetime!)
Deliver time	30workdays
MOQ	1set
Package	waxing

★★★★★Product Display :
